Name: VMC1060 High Precision Metal Mould CNC Vertical Machining Center
Machine Model : GY-VMC1060
4 Axis VMC1060 CNC Vertical Machining Center Application
Main Application:can be applied to many fields such as mechanical processing and mould manufacturing, canadapt from roughing to finishing processing requirements, has the characteristics of high precision, high efficiency, is widely used in aerospace, military industry, mould, automobile, internal combustion engines, textile machinery, chemical machinery processing, oil, electronics and other industries.
Main Parameters of 4 Axis vMC1060 Model CNC Vertical Machining Center
|
|
|
|
|
Specification |
Unit |
|
Model |
|
|
|
VMC1060 |
|
|
Table |
Size |
1200*600 |
mm |
||
|
Max. Table Load |
800 |
kg |
|||
|
T-slot No. and size |
5-18-100 |
mm |
|||
|
processing |
Table Travel (X) |
1000 |
mm |
||
|
Scope |
Table Travel (Y) |
600 |
mm |
||
|
|
Table Travel (Z) |
600 |
mm |
||
|
|
Spindle end face to Work surface distance |
Max. |
670 |
mm |
|
|
|
Min. |
70 |
mm |
||
|
|
Distance from Spindle center to Z Axes rail surface |
665 |
mm |
||
|
Spindle |
Spindle Taper (7:24) |
BT40-150 |
|
||
|
Range of Spindle Speed |
8000 |
r/min |
|||
|
Spindle Motor Power |
11 |
kW |
|||
|
Move |
Fast-moving |
X Axes |
18 |
m/min |
|
|
Y Axes |
18 |
||||
|
Z Axes |
18 |
||||
|
Moving speed |
1-10000 |
mm/min |
|||
|
Tool Magazine |
Tool Magazine style |
disc |
|
||
|
Tool Magazine Capacity |
24 |
|
|||
|
Min. Time of Tool Change |
2.5 |
s |
|||
|
Positioning Accuracy |
Accuracy testing standard |
JISB6336-4:2000/ GB/T18400.4-2010 |
|
||
|
X/Y/Z Axes |
0.008 |
mm |
|||
|
X/Y/Z Axe Repeatability |
0.005 |
mm |
|||
|
Dimension(L*W*H) |
3100*2200*2600 |
mm |
|||
|
Weight |
7500 |
kg |
|||
4 Axis vMC1060 Model CNC Vertical Machining Center Details for Reference
Samples of 4 aXIS VMC1060 CNC Machining Centers for Reference
More kinds Metal Milling Turning Moulding Grinding CNC Machining Centers for choosing
