Name: HMC1814 High Precision HMC Machining Center for Metal Milling and Carving
Machine Model : GY-HMC1814
HMC1814 Horizontal HMC Machining Center Machine Application
CNC machine tool HMC1814 Model Horizontal machining center can be used for: base, column, lifting sliding rail, head, main motor, main shaft, longitudinal slide rail, saddle, horizontal slide rail, workbench.
It is suitable for producing metal product and parts in all shapes. It is widely used to produce the auto spare parts, medical treatment instrument and any kind of injection mould, blowing mould, die-casting mould, car LED mould, toy mould and precise mould and so on.
Main Parameters of HMC1814 Model Precision Horizontal Machining Center Machine Tool
|
VMC1814 Technical Parameter |
|||
|
worktable |
Worktable size |
mm |
2000×900/800*800 |
|
Worktable max.load |
kg |
1600 |
|
|
T-slot (number*width) |
|
5-22-165 |
|
|
Travel |
X-aixs travel |
mm |
1800 |
|
Y-aixs travel |
mm |
1280 |
|
|
Z-aixs travel |
mm |
900 |
|
|
Distance from spindle nose to table surface |
mm |
200-1100 |
|
|
Distance from spindle center to column guideway |
mm |
140-1420 |
|
|
Spindle |
Spindle transmission type |
|
Belt type |
|
Spindle taper |
|
BT50 φ190 |
|
|
Spindle speed |
rpm |
6000 |
|
|
Spindle motor |
kw |
15 |
|
|
Feed Speed |
X/Y/Z-aixs rapid feed |
m/min |
18\12\18 |
|
Cutting feed speed |
mm/min |
1-10000 |
|
|
Tool magazine |
Tool number |
pcs |
24 |
|
Tools change way |
|
Disc type ATC |
|
|
Tool change time |
s |
2.5 |
|
|
Precision |
Positioning precision |
mm |
±0.008 |
|
Reported positioning precision |
mm |
±0.005 |
|
|
|
Dimension(L*W*H) |
mm |
4800*3800*3450 |
|
|
Weight |
kg |
15000 |
HMC1814 Model cNC Horizontal Machining Center machine tool Details for Reference
