Name : Large Aluminum Mould Making CNC Molding Milling Machine Center
Machine Model: GY-SG1530T
Main Information of Aluminum Mould Making CNC Molding Milling Machine
Aluminum Mould Making CNC Molding Milling Machine Application
Applicable materials:
Aluminum, Hard Wood, Polystyrene foam (EPS), wood, timber , High density PU, and nonmetallic carbon hybrid, and other non-metal materials.
Professional for 3D sculpture, Wood and foam 3D Pattern, 3D mockups, etc, cutting, engraving,milling and Molding..
Applicable industry :
Mold industry: large Alumuinum moulds, non-metal mold, particularly for lost foam pattern, FRP,
wood mold, car, ship,
aviation, spaceflight, locomotive&rolling stock, vessel, etc.
3D processing: cylinder, square sculpture and so on.
Cubic sculpture Field: used for making big size non-metal sculpture, City Plaza sculpture, Advertising sculpture, Hotel sculpture, etc..
Mold industries:
Die mould,casting, automotive, wind power, ships, boats, aerospace industry,
rail transport, sculpture various large non-metallic mold can be particularly suitable for any kind of Foam (EPS) mould, wooden ship model,wooden model aviation and other wooden mould.
It can manufacture the following effects: engraving, cutting, milling ,drilling, relief, shadow, enchase and so on.
Main Parameters of the Aluminum Mould Making CNC Molding Machine
Aluminum Mould Making CNC Molding Machine Parameter
|
Model |
GY-SG1530T-3S |
|
Lathe body |
Thick and Hard Steel structure (sand blast & seasoning) |
|
X Y effective working area |
1500*3000*1000mm |
|
Precision Machining |
0.1mm/1000mm |
|
Max Traverse Speed |
50000mm/min |
|
Max processing speed |
30000mm/min |
|
Table size |
1400*2700mm |
|
Resolution |
0.01-0.03 mm |
|
Spindle power rate |
7.5kw Water-cooled Mechanical Spindle |
|
Inverter |
Delta |
|
X,Y structure |
Rack and pinion transmission, Taiwan Hiwin Linear Bigger orbit |
|
Z structure |
Germany-made ball screw |
|
Motor of X , Y axis |
Yaskawa Servo Motor |
|
Motor of Z axis and 4th axis |
Servo |
|
Guide Rail |
Hiwin-35mm |
|
Small Electronic parts |
Schneider |
|
Spindle rotating speed |
0-24000r/min |
|
Standard Power |
AC380V-/220V-Three Phase (Optional) |
|
Max. idling speed |
30000mm/min |
|
Cooling mode |
Water-cooling |
|
Command |
G code,HPGL,U00,mmg,plt |
|
Dust-collect function |
Yes |
|
Clamping mode |
By Slots |
|
Operating system |
Taiwan Syntec 3axis Control System |
Samples made by CNC Aluminum Molding Milling Machine for Reference
